KR CYBERTECH

The industrial robots of the KR CYBERTECH family represent the world’s largest range of models in the low payload category with the greatest power density. They are ideally suited to space-saving cell concepts and provide top performance – with particularly low follow-up costs.

The powerful multi-function robots of the KR CYBERTECH series are specialized in handling applications: for handling large components, machining, assembly, palletizing and arc welding. They can be controlled with the KR C4 or KR C4 extended.

A key new feature of the KR CYBERTECH series is the even more compact design of the industrial robots. This enables you to benefit from the greater integration density and reduced disruptive contours. Choose the right industrial robot for every application from the wide-ranging portfolio.

8 - 22 Payload [kg]

1612 - 2013 Reach [mm]

Advantages


Fast and accurate

The industrial robots of the KR CYBERTECH series reach exceptionally high speeds, allowing them to work even faster – without any loss of precision.

Extensive portfolio

The KR CYBERTECH series is suitable for handling large components, machining, assembly, palletizing and arc welding. A number of special variants are at the planning stage.

Flexible installation

For planning security and low costs in the design of cells: the robots can be flexibly floor-, wall- or ceiling-mounted or even installed at a certain angle.

Variety of energy supply systems

Separation of the cable set and the dress package means that you can choose from a large variety of compatible energy supply systems.

Streamlined design

The KR CYBERTECH family is set apart by a streamlined wrist and an extremely compact and simultaneously athletic appearance.

Improved motion characteristics

The optimized controller structures make for smooth and sensitive motion characteristics – on the path and during positioning.

KR CYBERTECH Headline Addition

KR 20 R1810 KR 16 R2010 KR 22 R1610 KR 8 R2010 KR 16 R1610 KR 12 R1810
Category
Low Payloads (5-20 kg)
Low Payloads (5-20 kg)
Low Payloads (5-20 kg)
Low Payloads (5-20 kg)
Low Payloads (5-20 kg)
Low Payloads (5-20 kg)
Construction type
Standard1
Standard1
Standard1
Standard1
Standard1
Standard1
Extension 1
Standard1
Standard1
Standard1
Standard1
Standard1
Standard1
Extension 2
Standard1
Standard1
Standard1
Standard1
Standard1
Standard1
Version environment
Standard
Standard
Standard
Standard
Standard
Standard
Environment version extension
Standard
Standard
Standard
Standard
Standard
Standard
Payload
20 kg
16 kg
22 kg
8 kg
16 kg
12 kg
Total load
20 kg
16 kg
22 kg
8 kg
16 kg
12 kg
Maximum reach
1813 mm
2013 mm
1612 mm
2013 mm
1612 mm
1813 mm
Number of controlled axes
6
6
6
6
6
6
Position repeatability
±0,04 mm
±0,04 mm
±0,04 mm
±0,04 mm
±0,04 mm
±0,04 mm
Weight
150 kg
255 kg
245 kg
255 kg
245 kg
250 kg
Mounting positions
Ceiling / Floor / Wall
Ceiling / Floor / Wall
Ceiling / Floor / Wall
Ceiling / Floor / Wall
Ceiling / Floor / Wall
Ceiling / Floor / Wall
Ambient temperature
5 °C bis + 55 °C
5 °C bis + 55 °C
5 °C bis + 55 °C
5 °C bis + 55 °C
5 °C bis + 55 °C
5 °C bis + 55 °C
Controller
KR C4
KR C4
KR C4
KR C4
KR C4
KR C4
Protection class
IP 65
IP 65
IP 65
IP 65
IP 65
IP 65
Protection class inline wrist
IP 65
IP 65
IP 65
IP 65
IP 65
IP 65
Downloadcenter

1 Footnote Standard
